BS06K
RAYTOOLS
EMPOWER RAYTOOLS BS06K high power intelligent cutting head 6KW/8KW
BS intelligent cutting series|BS06K high power intelligent cutting head 6KW/8KW
Power level: 6KW/8KW
product features
Excellent design:
Lightweight design and fast acceleration;
At the same time, it has optimized optical configuration and smooth and efficient airflow design, which significantly improves cutting quality and efficiency;
Flexible control methods:
Support a variety of interfaces - analog and pulse to control the focusing unit, users can achieve continuous and rapid focus position adjustment through program settings;
High adaptability:
Equipped with QBH and G5 fiber interfaces, which can be adapted to various mainstream lasers;
APP real-time monitoring:
Through the wireless network, the monitoring data can be read on the mobile terminal and CNC system;
Parameter real-time feedback:
Various built-in sensors can provide real-time feedback of parameters in the processing process such as the temperature of the protective lens inside the cutting head, the temperature of the focusing lens, the temperature and humidity of the cavity, the air pressure in the cavity, and the air pressure of the cutting gas.
auto focus
- Range: -35mm~+25mm
- Speed: ≤200mm/s
- Acceleration: ≤10m/s2
- Accuracy: 0.01mm
Numerical aperture: 0.14
Nozzle specifications: single layer, double layer, non-standard
Nozzle hole diameter: 1.0mm, 1.2mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm, 4.0mm, 4.5mm, 5.0mm
Auxiliary gas pressure: ≤30bar
Weight: ~7.5kg
