How much do you know about the core components of a fiber laser cutting machine?
Fiber laser cutting machine has the advantages of faster, higher precision and can cut metal materials, and has already become an irreplaceable sheet metal processing equipment in many industries. The fiber laser cutting machine has a complex structure and many accessories, and its unique advantages are also reflected in high-tech accessories. The use of different types of accessories has a great impact on the performance parameters of the fiber laser cutting machine, so let's take a look at these types of accessories.
The key accessories of fiber laser cutting machine are lasers, motors, automatic control systems, laser cutting heads, laser lenses, etc.
Fiber Laser Generator
This is the key accessory of the fiber laser cutting machine, which is equivalent to the heart of the fiber laser cutting machine. The cutting performance quality of the fiber laser cutting machine is directly affected by the quality of the laser. So far, the well-recognized lasers are IPG from Germany, SPI from the United States, and Raycus Laser from China. Compared with laser generators of similar products, these are of better quality and more stable performance. It has the characteristics of durability and low operation and maintenance cost. Generally suitable for high power fiber laser cutting machine.
servo motor
The motor plays the function of controlling the mechanized operation in the servo control system. The cutting accuracy, positioning accuracy and repeated positioning accuracy of the fiber laser cutting machine are all related to it.
Automatic Control System
The automatic control system is equivalent to the brain of the fiber laser cutting machine. The control device achieves X/Y/Z reciprocating motion and controls the power output. Good control system, inclusive operation interface, easy operation, intelligent integration, closely related to the performance indicators of fiber laser cutting machine.
Laser cutting head
The laser cutting head is the output device of the fiber laser cutting machine, which is composed of a nozzle, a focusing mirror and a focus tracking system. The automatic control system and power system control the nozzle along the cutting path to complete the cutting.
Considering the difference in material and thickness, the height of the laser cutting head is also different. It is necessary to complete the main parameters with the help of an automatic control system to ensure the safety of fiber laser cutting.
laser lens
The laser beam lens plays a very important role in the laser system, which is related to the power of the fiber laser cutting machine. According to the different needs of cutting quality, the cost of domestic brand lenses and imported lenses is quite different, and the service life and quality are also very large.
