EMPOWER RAYTOOLS BW290-6B dual-band compound swing welding head 6KW
BW welding series｜BW290-6B dual-band compound swing welding head 6KW
Power level: 6KW
Product features
High power welding:
Able to withstand 4KW (optical fiber) + 2KW (semiconductor) high power compound swing welding
High welding quality:
Low porosity, high mechanical properties, high quality weld surface
Rich scan graphics:
Continuous welding supports continuous circle, continuous straight line, continuous 8 type, continuous S type; spot welding supports spot welding circle, spot welding straight line, spot welding S type, spot welding C type, and spiral type
Drawer mounts:
Quick and easy replacement of protective lenses
High degree of dust protection:
Reliable sealing design can effectively avoid optical lens pollution and improve service life
Efficient cooling:
Double water-cooling structure design, the lens holder of the protective mirror and the laser head body are equipped with water-cooling interface, which prolongs the continuous working time
Power level: fiber 4000W + semiconductor 2000W
Laser wavelength: fiber 1064nm, semiconductor 915/450nm
Clear aperture: fiber 30mm, semiconductor 48mm
Weight: ~12.0kg
