PORAD Powelder2.0 4000W Fiber Laser Welding Head for fiber Laser Welding machine
1. Description:
Powelder 2.0 is a 4000W fiber laser welding processing head launched by PORAD in 2019.
2. Technical parameters:
Interface type: QBH
Applicable fiber power: ≤4000W
Focusing lens focal length: 200mm
Upper protective mirror specification: ø 30mm*1.5mm
Lower protective mirror specification: ø 38mm*2mm
CCD connection module: TYPE-C, TYPE-CS
Auxiliary gas pressure: ≤2.5MPa
Air knife: 6bar
3. Feature description:
Abundant expansion modules: modules such as welding seam tracking or positioning function can be expanded, which is easy to realize automatic welding.
High-quality airflow design: Coaxial, side-shaft protection nozzles and air knives adopt smooth and efficient fluid structure design, which can obtain the best molten pool protection effect and welding slag blowing effect.
High-quality dust-proof: double protection lens design, increase the service life of welding head.
Built-in cooling: Both the collimating lens and the focusing lens holder have excellent water cooling, which prolongs the service life of the lens.
1) Laser and laser welding machine:
The laser welding machine consists of a laser and a welding head, and the laser is the core component of the laser welding machine. The company's laser products cover blue laser series, YAG laser series, fiber laser series, compound laser series, semiconductor laser series, pulse laser series;
2) Workbench:
It is composed of mobile platform and operation control system, mainly including three-dimensional stage (duplex, rotary, cantilever, high-speed, standard and other categories), standard galvanometer stage, robot welding station, etc.;
3) Laser welding automation equipment:
For power battery cell and module assembly, fuel cell bipolar plate and other application scenarios, combined with electrical automation, mechanical technology and other categories of design, it is composed of laser welding machine and workbench loaded with automation system software and application environment design. An automated complete solution that integrates the working functions of several laser welding machines and workbenches into an automated assembly line.
