Precision Laser Cutting Services — Prototype SMT Stencils (Frameless)

Our frameless SMT stencils are precisely laser-cut and engineered specifically for manual solder paste application on prototype printed circuit boards (PCBs). These stencils are ideal for early-stage development, offering a fast, clean, and repeatable method of applying solder paste—eliminating the need for tedious hand soldering.

✅ Key Features:

• High-Precision Laser Cutting: Ensures accurate aperture dimensions and clean edges for consistent solder paste deposition.

• ⏱ Faster Assembly: Significantly reduces prototype PCB assembly time, speeding up your product development cycle.

• Frameless Design: Compact, cost-effective, and compatible with various manual stencil printers and jigs.

• Optional Flaps: Available with or without flaps, depending on your handling and alignment preferences.

• Ideal for Small Batch or Prototype Runs: Suitable for start-ups, R&D departments, and electronics engineers.

Applications:

• Prototype PCB assembly

• R&D solder paste testing

• Manual SMT paste printing

• Low-volume production

• DIY electronics projects
