BW101
3 in 1 :cutting/welding/cleaning Head. Cost-effective ,can clean the weld seam.
Product characteristics
Single galvanometer handheld welding head:
Light weight, small size, simple operation, ergonomic design
Safety protection:
Multiple safety protection, no light can come out when leaving the workpiece, high safety
Optimized design:
Double protective window design, dust and slag prevention design, stable and reliable products
Process advantages:
Continuous welding, fish scale spot welding, suitable for various welding methods
Three-in-one function:
Equipped with multi-purpose nozzle selection to meet the common functions of welding, cutting and cleaning
Technical parameter
Power grade: 2000W/3000W
Optical aperture: 14mm
Swing amplitude: 0-5mm
Applicable wavelength: 1070nm
Weight:~0.9kg
Interface Type | QBH |
Power Range | Below 2000W |
Laser Wavelength | 1064-1080 |
Mark Width | 0.2-5.0mm |
Colliamating Length | 50 |
Focal Length | 120/150 |
Protective lens | D20*2 |
Cooling Way | Water |
Weight | 1.2kg |
