FSCUT 8000B Laser Cutting Machine System Laser Parts

FSCUT8000 is EtherCAT bus system designed for ultra high power fiber laser above 8KW, featured by out of box service, easy to install and adjust, full solution functions. It supports customization, automation and informatization solutions, is the leading edge EtherCAT laser cutting control system on the market.
Availability:
Quantity:
  • FSCUT 8000B

  • FSCUT

Product Description

FSCUT 8000B Laser Cutting Machine System Laser Parts

Model HypTronic HyPanel HPL2720E BCS100E




Hardware CPU Intel I5 6440EQ(4-core 3.4GHz) Panel 21.5 inch 1080P Capacitive multi-touch screen
Load
Overall highest output2.5A
Feature
Maximum acceleration 3G
Memory Dual-channel 8G DDR4-2133 Communication BC-LINK video and data transmission (100m)
Single channel highest output 700mA
Maximum speed 999mm/s
Disk 64GB SSD mSATA Feature Multi-function rotary knob Communication EtherCAT Bus (100M) Communication EtherCAT Bus (100M)
System 64-bit Windows 10 LTSB Operation 17 operation buttons (include E-Stop) Accuracy PWM accuracy:50KHz (0.1%) Accuracy 0.001mm
Resource
Video
BC-LINK * 1
Data BC-LINK * 1
Input
Common input * 27

DVI-D * 1
Button Button * 15
NPN type (3PNP)
LAN
EtherCAT * 1
Knob Knob * 1
Output
DA * 4
EtherNET *3
E-stop E-STOP * 1
PWM * 1PWM * 1
USB USB 3.0 * 4 USB USB 2.0 * 2
Common output * 20


Thyristor 24V output
Power supply Voltage DC 24V Voltage DC 24V Voltage DC 24V Voltage DC 24V
Current 4A Current 3A Current 3.5A Current 1A
Other
Pre-install RTOS real time system
Support up to 100m USB and display signal of stable transmission
Support up to 32 I/O slave-station extension
PRECITEC laser head can work with BCS100E-PRO height controller

FSCUT8000B

FSCUT8000B LASER MACHNINELASER CUTTING MACHINE SYSTEM

FSCUT8000
