3KW Fiber Laser Wobble Welding Head For Laser Welding Solutions WSX ND24A Metal Fiber Laser Welder Machine
Detailed information：
1.This wobble welding laser head is Cost-effective, having a
strong advantage in welding aluminum alloy and medium power
welding.
2.It adopts the motor to drive the X, Y-axis galvanometer lens
with a variety of wobbling modes. It significantly improves the
welding performance, like allowing the work piece with irregular
weld seam or large gap.
3.Full-sealed internal structure protects optical part from dust
pollution.
4.Air curtain parts prevent welding slag from entering head inside.
Protective window cartridge makes faster change.
Air curtain is optional.
Product parameters：
Maximum power 1500W
Collimated focal length 100mm
Focusing focal length 200mm
Weight 3.6 kg
Effective clear aperture ￠27mm
Can be used with various lasers
Main function introduction:
QBH components
The core connector for connecting to the laser fiber, providing an industry standard fiber access port.
Collimator Assembly
The collimating lens is assembled in the laser head, and includes a collimating lens cavity, a biconvex lens, a washer, and a locking elastic ring.
Galvo assembly
The motor drives the X and Y axis vibrating lenses, which have multiple swing modes, expand the area of the weld, and allow the workpiece to have irregular welds and larger gaps.
CCD components
Provide filtered light source to provide safe, reliable and real light source for CCD.
Focus Components
The focusing assembly is assembled in the laser head, including a focusing lens group, a focusing lens cavity, a washer, a locking spring ring and a water cooling system for lens cooling.
Protective mirror assembly
So that the welding slag can not directly splash on the focusing lens, protect and prolong the use time of the focusing lens.
Air curtain assembly
Blows away the bounced slag to protect the protective mirror.
