TL310 Circular Powder Feeding Laser Processing Head for laser cladding 3D printing laser welding and other metal processing applications

The image provides an introduction to the TL310 Circular Powder Feeding Laser Processing Head used in laser processing.
Availability:
Quantity:
  • TL310

Product Description

The image provides an introduction to the TL310 Circular Powder Feeding Laser Processing Head used in laser processing.

商品抠图

TL310 Circular Powder Feeding Laser Processing Head

Product Introduction

The TL310 is a highly cost-effective laser processing head designed for circular powder feeding. Its modular design allows for easy integration into various systems for different application scenarios. It has been widely used in industries such as laser cladding, 3D printing, laser welding, and other metal processing applications. The head's deep design for cladding applications and its adaptable configuration options meet the diverse needs of industrial applications.

Features:

  • Adjustable Powder Feeding Structure: Flexible powder delivery for efficient processing.

  • Dual Internal Water-Cooling Design: Ensures stable performance during high-power applications.

  • Support for Multiple Sensors (Temperature, Focus Positioning, and Monitoring): Enhances the precision and reliability of operations.

  • CCD Integration Capability: Allows for real-time process monitoring.

  • Optimized for High Precision: Ensures consistent, high-quality results in various laser processing tasks.

Technical Parameters:

  • Power Capacity: 3 kW

  • Collimation Lens: 100mm, 150mm

  • Focus Lens: 200mm, 250mm, 300mm

  • Spot Size: 0.05-2mm

  • Powder Feeding Diameter: 0.27-0.74mm/0.41-1.1mm

  • Protective Lens Size: Diameter of 36mm and thickness of 7mm

  • Nozzle Angle: 30° or 45°

  • Powder Feeding Method: Supports coaxial and circular powder feeding
